Width: 76.2 mm (3 in)
Height: 40.6 mm (1.598 in)
Length: 127 mm (5 in)
Industry: Industrial
Approvals: EN60950-1, IEC60950-1, UL/CSA60950-1
Compliance: EN60950-1, IEC60950-1, UL/CSA60950-1
Efficiency: 70 %
Output Power: 40 W
Input Voltage: 90 VAC to 264 VAC
Mounting Style: Chassis
Input Frequency: 47 Hz to 63 Hz
Load Regulation: Regulated
Isolation Voltage: 4.242 kVDC
Number of Outputs: 3 Output
Power - Convection: 40 W
Open Frame/Enclosed: Open Frame
Output Current-Channel 1: 5 A
Output Current-Channel 2: 1 A
Output Current-Channel 3: 300 mA
Output Voltage-Channel 1: 5 VDC
Output Voltage-Channel 2: 12 VDC
Output Voltage-Channel 3: - 12 VDC
Operating Temperature Range: 0 C to + 70 C
Maximum Operating Temperature: + 70 C
Minimum Operating Temperature: 0 C
