Product Features:
European Plug Model
Full-Spectrum Absorbance Scanning and Calculations of 260/280 and 260/230 Ratios
Long-Life Xenon Lamp with Precision Monochromator
Auto-Ranging Path Lengths of 0.05mm, 0.2mm and 1.0mm
Detect Up to 15,000ng/µl of dsDNA Without Dilution
Integrated Fluorometer for Sensitive Quantitation of Low Concentration Nucleic Acids
Specifications:
Display: 7-inch touch screen
Minimum sample size: 0.5µl - 2.0µl
Path length: 0.05mm, 0.2mm, 1.0mm
Light source: Xenon Flash Lamp
Detector: 2048 Element Linear Silicon CCD Array
Wavelength: 200 - 800nm (1nm steps)
Absorbance range: 0.04 - 300 A (10mm equivalent)
Absorbance precision: 0.003 A
Lower limit of detection: dsDNA: 2ng/µl ; BSA: 0.1mg/ml
Upper limit of detection: dsDNA: 15,000ng/µl; BSA: 360mg/ml
Detection time: < 6 seconds
Communication ports: USB for data export
Voltage input: DC 24V, 2A
Power: 25W
Dimensions (WxDxH): 20.8 x 28.0 x 18.6 cm / 8.2 x 11.0 x 7.3 in.
Weight: 3.6 kg / 7.9 lbs
Cuvette OD600 detection:
Absorbance range: 0.0 - 4.0 A
Absorbance stability: [0,3) ≤ 0.5%, [3,4) ≤ 2%
Absorbance repeatibility: [0,3) ≤ 0.5%, [3,4) ≤ 2%
Absorbance precision: [0,2) ≤ 0.005 A, [2,3) ≤ 1%, [3,4) ≤ 2%
Fluorescence detection:
Excitation/Emission**: 460 ± 20nm / 525-570nm
Sensitivity: dsDNA: 0.5pg/µl
Linearity: R² ≥ 0.995
Repeatibility: ≤ 1.5%
Stability: ≤ 1.5%
