Frequency Range: 350 MHz to 4.0 GHz
Power Range: 0.15 W to 150 W
Impedance: 50Ω
Insertion VSWR: 1.1 Max
Insertion Loss: 0.1 dB Max
Response Time: 3 sec.
VSWR Range: 1.15 to 99.9
Connectors: N (F)
Power Supply:
Source: 5Vdc from USB host
Current Draw: 35 mA
Weight: 1.0 lbs (0.45 kg)
Dimensions H x W x D: 4.8 in x 2.6 in x 1.3 in/ (122 mm x 66 mm x 32 mm)
Operating Temperature: -30 °C to +60 °C (-22 °F to +140 °F)
Storage Temperature: -40 °C to +80 °C (-40 °F to +176 °F)
CE: EMC EN 61326-1-2006
