Input Voltage: 0-80 V
Input Current: Low: 0-3A; High: 0-20 A
Input Power: 250 W/50 W
Channel: 2
Minimum operating voltage: Low: 0.10 V at 4 A; high: 1 V at 40 A
Mode Regulation: CV, CC, CR, CW
Measurement: A, V, W
Over-Current/Over-Voltage/Over-Power/Over Temperature Protection
General (typical)
Short Circuit:
Current (CC): Low: 3A; High: 30A
Voltage (CV): 0 V
Resistance (CR): 50 mΩ
Input Terminal Impedance: 300 kΩ
Safety: EN61010-1:2001, EU Low Voltage Directive 2006/95/EC
Dimensions: 3.2” x 7.2” x 22.6” (82 x 183 x 573 mm)
Weight: 11 lbs (5 kg)
