RF Frequency Range: 50 MHz to 40 GHz
Video Bandwidth (high/std): 6 MHz / 350 kHz
Dynamic Range
Average: -50 to +20 dBm
Pulse: -40 to +20 dBm
Power: Consumption 2.5 W max (USB High-Power device)
Rise Time (fast/std): 4 ns / < 10 μs
Video Bandwidth (high/std): 165 MHz / 350 kHz
Single-shot Bandwidth: 35 MHz
RF Input Type: Type N, 50 Ω
VSWR: 1.20 (0.05 to 6 GHz); 1.25 (6 GHz to 8 GHz)
Dimensions: (H x W x D) 1.7” x 1.7” x 5.7” (4.3 cm x 4.3 cm x 14.5 cm)
Weight: 0.8 lbs (0.36 kg)
Standard Accessories: 0.9 m BNC (m) to SMB (m) cable, 0.9 m SMB (m) to SMB (m) cable, 1.8 m USB A (m) to USB B (m) locking SeaLATCH cable, power cord, test report & certificate of calibration
