Width: 2.8 mm
Height: 0.94 mm
Length: 4.8 mm
Resistance: 1.2 mOhms
Maximum Voltage: 28 VDC / 35 A, 100 cycles
Rated Temperature: + 77 C
Reset Temperature: + 40 C
Maximum Leakage Current: 200 mA
Minimum Holding Voltage: 3 V
Maximum Breaking Current: 5 VDC / 70 A, 100 cycles
Maximum Operating Temperature: + 100 C
Minimum Operating Temperature: - 30 C
