Bourns SD70WBB Thermal Cutoff Devices TCO, High Current, SMD, 70C, non Self Hold AEC-Q200
Manufacturer: Bourns Model: SD70WBB - Contact
Width: 3.75 mm
Height: 1.4 mm
Length: 6.95 mm
Resistance: 4 mOhms
Qualification: AEC-Q200
Contact Rating: 14 VDC / 8 A, 10000 cycles
Maximum Voltage: 14 VDC / 8 A, 10000 cycles
Rated Temperature: + 70 C
Reset Temperature: + 20 C
Maximum Leakage Current: 300 mA
Maximum Breaking Current: 14 VDC / 8 A, 10000 cycles
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 40 C
