Width: 6.6 mm
Height: 2.8 mm
Length: 7.3 mm
Core Type: Wirewound
Q Minimum: 10
Shielding: Shielded
Tolerance: 20 %
Inductance: 330 nH
Application: Automotive
Termination: Standard
Unit Weight: 750 mg
Core Material: Ferrite
Qualification: AEC-Q200
Mounting Style: PCB Mount
Test Frequency: 100 kHz
Termination Style: SMD/SMT
Maximum DC Current: 32 A
Saturation Current: 32 A
Maximum DC Resistance: 3.9 mOhms
Self Resonant Frequency: 140 MHz
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 40 C
