Width: 3.2 mm
Height: 2.8 mm
Length: 3.5 mm
Core Type: Wirewound
Q Minimum: 18
Shielding: Shielded
Tolerance: 30 %
Inductance: 22 uH
Application: Automotive
Termination: Standard
Unit Weight: 125 mg
Core Material: Ferrite
Qualification: AEC-Q200
Mounting Style: PCB Mount
Test Frequency: 2.52 MHz
Termination Style: SMD/SMT
Maximum DC Current: 600 mA
Saturation Current: 620 mA
Maximum DC Resistance: 335 mOhms
Self Resonant Frequency: 15 MHz
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 40 C
