Printing Technology: Thermal Transfer, Direct Thermal
Resolution: 203 dpi
Maximum Print Width: up to 108 mm
Print Speed: up to 177 mm/s
Printable Media: Paper, cardboard, synthetic materials in roll or fanfold form
Label Width: 25 – 112 mm
Continuous Liner Width: 25 – 118 mm
Label Height: from 4 mm up to 762 mm
Material Thickness: 0.06 – 0.2 mm
Media Weight: 60 – 160 g/m²
Roll Outer Diameter: up to 127 mm
Core Diameter: 25.4 – 38.1 mm
Winding: Inside or outside
Ribbon Winding: Inside or outside
Ribbon Roll Diameter: up to 68 mm
Ribbon Core Diameter: 25.4 mm
Ribbon Length: up to 300 m
Ribbon Width: 25 – 114 mm
Dimensions (W × H × D): 210 × 186 × 280 mm
Weight: 3 kg
Gap Sensor: Fixed in center
Reflective Sensor from Below: Adjustable
Memory: 16 MB Flash, 8 MB SDRAM (4 MB available for applications)
Battery: Battery for current date/time, real-time clock
Interfaces: RS232C, USB for PC, Ethernet, USB Host
Control Panel: Power On/Off button, Material Sensor Calibration, TFT color display with navigation panel
Power Supply: 100 – 240 VAC, 50/60 Hz, PFC
Power Consumption: 60 W
