Laser Source: Ytterbium fiber laser, pulsed
Output Power: 20 W, 30 W
Pulse Energy: 1 mJ
Wavelength: 1,064 nm
Beam Quality (M²): < 1.8
Pulse Width: < 120 ns
Pulse Frequency: 20 – 60 kHz
Working Distance: 210 ± 8 mm
Marking Field: 112 × 112 mm
Device Dimensions (W × H × D): 420 × 480 × 480 mm
Weight: < 35 kg
Laser Protection Window (W × H): 100 × 200 mm
Rear Connections: 2 × Ethernet TCP/IP, AF5 extraction and filtration system, external start, external E-stop
Power Supply: 100 – 240 VAC, 50/60 Hz
Power Consumption: Standby < 35 W / Typical 150 W / Up to 200 W
Marking Software: cabLase Editor 5 with cabLase automation
