AC Mode Output
Frequency Range: 16.00-1000 Hz
Total Power: 3000 VA per phase, 3 phases
Load Power Factor:0 to unity at full output VA
AC Mode Voltage
Ranges: VLow: 0-150V; VHigh: 0-300 V
Output Noise (20 kHz to 1 MHz):< 250 mVrms typ.; < 500 mVrms max.
Harmonic Distortion (Linear):< 1% from 16 - 66 Hz, < 2% at 400 Hz, < 3% at 800 Hz (Full resistive load)
DC Offset:< 20 mV External Amplitude Modulation: Depth: 0 - 10 %, Frequency: DC - 2 KHz
Isolation Voltage:300 Vrms output to chassis
AC Mode Current
Steady State AC Current: 300 V range: 11.1 /ø; 150 V range:22.2 /ø
Peak Repetitive AC Current: High range: 96.0 /ø; Low range: 110.0 /ø
DC Mode Output
Power (Max at full scale of DC Voltage Range): 2100 W/ø 3ø
Voltage Ranges:Range: Low: 200 Vdc, High: 400 Vdc
Line Regulation:< 0.1% FS or 10% line change
Output Noise:< 250 mV rms typ., < 500 mV rms max., (20 kHz to 1 MHz)
Max DC Current (Maximum current at 65% of V Range)
400V range:7.8
200V range:15.6
AC+DC Mode Output
Please check the datasheet for details
