Rated input voltage: 24VDC
Measurement range: 2.0 ～ 500.0 [mN・m]
Unit of measure: mN・m / cN・m
Accuracy: ±1.0% (±5 digits for 499 digits or less)
Sampling period: 1000 data / 1 second
Rotational speed: 5 to 50 [rpm] *Adjustable every 5 rpm
Control angle: About 0.968°
Rotation angle: Can be set from 1° to 9999°
Communication port: USB, RS232C
External port: 1ch input, 3ch output
