Function: Max. Range - Basic Accuracy
Voltage DC: 1000V ; ±(0.1%+4d)
Voltage AC: 1000V ; ±(1.0%+3d)
Current DC: 1000A ; ±(2.5%+5d)
Current AC: 1000A ; ±(2.5%+5d)
Resistance: 50MΩ ; ±(3.0%+5d)
Temperature: 1000ºC/ 1832ºF ; ±(1.0%+2.5°C/4.5°F)
Capacitance: 5mF ; ±(3.5%+10d)
Frequency: 10MHz ; ±(0.3%+2d)
ACA flexible clamp: 3000A ; ±(2.8%+8d)
Size(HxWxD): 230mm x 76mm x 40mm
Weight: 315g
Accessories: Test leads, gift box with carrying case, Temperature probe and 9V battery.
Datasheet
Features | 3385 | 3386 |
Current measurement | AC | AC/DC |
LCD display counts with backlight | 50000 | 50000 |
3000A ACA Flexible clamp | * | * |
AC True RMS | * | * |
Flashlight | * | * |
Data Hold & Peak Hold | * | * |
Max /Min | * | * |
REL (Zero) Function | * | * |
Auto Power Off | * | * |
Low battery indication | * | * |
1.9” (48mm) Jaw opening | * | * |
NCV Detection & flashlight | * | * |
Inrush Current | * | * |
