Voltage DC (Maximum; Max. resolution; Best Accuracy): 1000V; 100mV; ±(0.5% + 5d)
Voltage AC (Maximum; Max. resolution; Best Accuracy): 1000V; 100mV; ±(1.2% + 5d)
Current DC (Maximum; Max. resolution; Best Accuracy): 1000A; 0.01A; ±(2% + 8d)
Current AC (Maximum; Max. resolution; Best Accuracy): 1000A; 0.01A; ±(2.5% + 5d)
Flexible A (Maximum; Max. resolution; Best Accuracy): 3000A; 0.01A; ±(3.0%+5d)
Resistance (Maximum; Max. resolution; Best Accuracy): 60MΩ; 0.1Ω; ±(0.8% + 5d)
Capacitance (Maximum; Max. resolution; Best Accuracy): 100mF; 0.01nF; ±(3.0% + 5d)
Frequency (Maximum; Max. resolution; Best Accuracy): 10MHz; 0.01Hz; ±(0.2% + 5d)
Inrush Current (Maximum; Max. resolution; Best Accuracy): 1000A; 1A
Temperature (Maximum; Max. resolution; Best Accuracy): 1000°C/1832°F; ±(1.5%+3°C)
Diode & Continuity: Yes
Interface: Bluetooth
Power Supply: Li-ion rechargeable battery
IR resolution: 80x80 pixels
Field of View (FOV): 21° x 21°
Thermal sensitivity/NETD: <0.08°C/80mK
Image frequency: 50Hz
Object temperature range: -20~260°C (-4~500°F)
Spectral range: 8-14 µm
Color palettes: Iron/Rainbow/Grey/Grey Inverted/Feather
Accuracy: ±2°C (±3.6°F) or ±2% of reading
Size (HxWxD): 95mm x 270mm x 42mm
Weight: 550g
Accessories:
Test leads, gift box with carrying case, Temperature probe, Li-ion rechargeable battery, AC Charger
