Measure range: 10%~97%/99.99% O2
Sensor: 3D Ion flow oxygen sensor
Accuracy: ±1% FS
Repeatability: ±0.5% FS
Stability: ±0.5% FS/7d
Response time: T90<20s (after full preheating)
Display resolution: 0.01%
Standby time: more than 8 hours
Sensor life: more than 2 years (normal use)
Instrument life: more than 5 years (normal use)
Power supply: 85~264VAC,50/60Hz
Analyzer power consumption: <25VA
Display: 128×64 LCD
Key: Four keys (touch keys)
Instrument weight: net weight is about 4.2 kg
Environment temperature: -10~45°C
Environment humidity: <80%RH
Sample gas pressure: atmospheric conditions±10% (Gas outlet should be atmospheric conditions)
Sample flow rate: 400~600ml/min
Alarm output: 1 set, Relay contact point capacity:24VDC,0.2A
Analog output: 1 set,4-20mA/0-20mA/0-1V/0-5V/0-10V/ 1-5V,(You can set the mode freely).
Communication: RS485(standard)/RS232(optional)
