DIELECTRIC
Nominal test voltage (50 Hz)*: 1000 V~1500V
Test voltage:
Range: 0...2.00 kV
Test current:
Range: 0...199.9 mA/ 200...500 mA
INSULATION RESISTANCE
Range: * 0...1.999 MΩ 2.00...19.99 MΩ
Mains voltage : 230 V / 50 Hz
Working humidity : 85% RH max (0...+40°C)
Dimensions (W x D x H) : 400 x 260 x 250 mm
Weight : 11 kg
Instruments supplied with :
1 mains lead, 3-core,
1 set of 2 keys to lock the instrument,
2 high voltage guns (2 m cable),
1 discharge cable,
2 continuity leads 2.5 m, with double
contact crocodile clips,
2 safety leads 3 m (red/ black),
2 crocodile clips (red/ black),
1 test prod (red), 1 carrying bag
for the accessories and the user manual
