Measurement Condition: d/8 (scattered light source, 8 degree observation angle), SCI (including specular reflection component).
Integrating Sphere: Φ40mm，Avian-D Full diffuse reflective surface coating
Light Source: CLEDs
Sensor: Dual Optical Path Array Sensor
Measurement Distance: 0.5mm
Internal Self-calibration: Built-in black and white calibration
Protection Level: IP67
Wavelength Range: 400-700nm
Wavelength Pitch: 10nm
Half Band Width: 5nm
Measuring Range: 0-200%
Resolution: 0.01%
Measuring Caliber: φ10mm（φ4mm optional）
Measuring Light Source: A,C,D50,D55,D65,D75,F1,F2,F3,F4,F5,F6,F7,F8,F9,F10,F11,F12,CWF,U30.DLF,NBF,TL83,TL84.U35
Display: Spectrogram/data, sample chromaticity value, color difference value, pass/fail result, color deviation, display measurement area, historical data color simulation, manual input of standard sample, generation of test report
Intervals: 1s
Measuring Time: Minimum 20ms
Measurement Parameter: CIE-L*a*b,L*C*h,L*u*v,XYZ,Yxy,Reflectivity
Color Difference Formula: ΔE*ab,ΔE*CH,ΔE*uv,ΔE*cmc(2:1),ΔE*cmc(1:1),ΔE*94,ΔE*00
Other indicators: WI(ASTM E313-00,ASTM E313-73,CIE/ISO,AATCC,Hunter,Taube Berger Stensby),YI(ASTM D1925,ASTM E313-00,ASTM E313-73),Tint(ASTM E313,CIE,Ganz) metamerism index Milm, color fastness, color fastness
Repeatability: Chromaticity value: ΔE*ab standard deviation within 0.03, maximum value 0.05 (After calibration, 30 times standard deviation of whiteboard is measured at intervals of 5 s)
Inter-instrument Agreement: Within ΔE*ab 0.2 (average of BCRA Series II 12 swatches)
Light Source Life: Lifetime warranty
Operating Environment: 0°C-45°C, relative humidity 80% or lower (at 35°C), no condensation
Storage Environment: -25°C-55°C, relative humidity 80% or lower (at 35°C), no condensation
Communication: Industrial USB, other interfaces can be customized
Power: +12DCV
Weight: 1.3kg
Size: 100*112*120mm(L*W*H)
