Cincon EC2A25S Isolated DC-DC Converter, 1.5 Watt, 24VDC Input, +/-15VDC Output, 500VDC min. Isolation, Non-Conductive Black Plastic, SMD

Width: 20.3 mm

Height: 10.2 mm

Length: 31.8 mm

Dimensions: 31.8 mm x 20.3 mm x 10.2 mm

Efficiency: 50 %

Unit Weight: 12 g

Output Power: 1.5 W

Input Voltage: 21.6 V to 26.4 V

Cooling Method: Convection

Mounting Style: SMD/SMT

Mechanical Style: Isolated

Isolation Voltage: 500 V

Number of Outputs: 2 Output

Input Voltage - Max: 26.4 V

Input Voltage - Min: 21.6 V

Input Voltage, Nominal: 24 V

Output Current-Channel 1: 50 mA

Output Current-Channel 2: 50 mA

Output Voltage-Channel 1: 15 V

Output Voltage-Channel 2: - 15 V

Maximum Operating Temperature: + 71 C

Minimum Operating Temperature: - 25 C
