Width: 52 mm
Height: 35 mm
Length: 72 mm
Region: North America
Industry: Industrial
Approvals: IEC/EN 60950-1, UL 60950-1
Compliance: IEC/EN 60950-1, UL 60950-1
Efficiency: Level VI
Output Power: 15 W
Input Voltage: 90 VAC to 264 VAC
Connector Type: Barrel Connector
Cooling Method: Convection
Mounting Style: Wall Mount
Load Regulation: Regulated
Mechanical Style: External
Center Pin Length: 9.5 mm
Isolation Voltage: 4.24 kVDC
Number of Outputs: 1 Output
DC Output Connector: 1.7 mm Barrel Plug (1.7x4)
Input Voltage - Max: 264 VAC
Input Voltage - Min: 90 VAC
Connector A Polarity: Center Positive
DC Output Cord Length: 1.8 m
Output Current-Channel 1: 630 mA
Output Voltage-Channel 1: 24 VDC
AC Plug included/required: Included
Operating Temperature Range: - 20 C to + 60 C
Maximum Operating Temperature: + 60 C
Minimum Operating Temperature: - 20 C
