Ranges and Transconductance
Range / Output Current / Transconductance
100A / 20A to 100A / 100 Siemens
20A / 2A to 40A / 10 Siemens
2A / 0.2A to 4A / 1 Siemen
0.2A / 20mA to 0.4A / 100 Millisiemens
20mA 2mA to 40mA 10 Millisiemens
2mA 0.2mA to 4mA 1 Millisiemen
10 Minute Transconductance Stability
0% - 100% of Full Scale / 100% - 200% Full Scale*
Frequency: (% Reading + % Range) / % of Reading
DC: ±(0.002 + 0.002) / ±0.004
10Hz to 10kHz: ±(0.005 + 0.005) / ±0.010
Transconductance Uncertainty (1year)
0% - 100% of Full Scale / 100% - 200% Full Scale*
Frequency : ±(% Reading + % Range) / % Reading
DC: ±(0.02 +0.02) / ±0.04
10Hz to 10kHz: ±(0.05 +0.05) / ±0.10
Compliance Voltage: 7VRMS for AC and 7V for DC. Display accuracy is ±0.10V
Total Harmonic Distortion:
-60db from 10Hz to 10kHz
-50db to 50kHz (8200)
-40db to 100kHz (8200)
Noise: 0.05% of current range in a band from DC to 100kHz
Inductive loads: Free from oscillations up to 1mH
Input impedance: 500kΩ from each terminal to ground
Frequency measurement accuracy: 0.01% of reading
Display: LCD color, graphical, touch sensitive
Temperature Range: Operating: 10˚C to 35˚
Within specifications: 18˚C to 28˚˚
Storage: -20˚C to 60˚C
Relative Humidity: less then 80%
Warm-up time: Thirty minutes for full specifications
Power Requirements: 207V to 235V, 50Hz to 60Hz, 2500VA power factor corrected
Physical
Weight: 80 lbs. (36.4 Kilograms)
Dimensions: 17” (43.2cm) X 20” (50.8 cm) X 12.25” (31.1 cm)
