Alternative Measurement Units: mg/Nm³; mg/m³; Vol.%
Accuracy: <2% of range
Flue Gas Temperature: 0 – 1200°C
Ambient Temperature: -20°C to 50°C
Zero Drift: Automated daily zero calibration
Span Drift: Manual span calibration on demand
Response Time (T90): < 180 seconds
Outputs: 1 x RS485 (standard); 16 x analog outputs (optional); 16 x relay outputs (optional)
Inputs: 1 x 4–20 mA input; 3 x digital inputs
Software: Local touch screen HMI; CODEL Cloud compatible
Power Supply: 240 VAC (-15% to +10% from nominal supply)
Power Consumption:
Cabinet: 15 kW
Sample line: 80 W per meter (typical, supplier dependent)
Sample probe: 800 W (typical, supplier dependent)
Air Supply: Oil-free instrument air; 1 L/min (standard operation); 10 L/min (calibration); @ 5.5 Bar (minimum)
Repeatability: <2% of range
Heated Sample Line (Dual Core): Sample and span gas lines with self-regulating heating up to 180°C; mains supply for sample probe
Standard Probe & Sample Line: Sample probe and sample line temperatures should be selected based on specific application conditions
Stack Gas Temperature: 0 – 300°C / 0 – 600°C / 0 – 900°C (options available)
