Width: 78.74 mm (3.1 in)
Height: 30.48 mm (1.2 in)
Length: 86.36 mm (3.4 in)
Industry: Industrial
Input Type: 1-Phase / Single Phase
Unit Weight: 235 g
Output Power: 15 W
Input Voltage: 85 VAC to 264 VAC, 120 VDC to 350 VDC
Mounting Style: DIN Rail Mount
Isolation Voltage: 3 kVAC
Number of Outputs: 2 Output
Open Frame/Enclosed: Enclosed
Output Current-Channel 1: 500 mA
Output Current-Channel 2: 1 A
Output Voltage-Channel 1: 15 VDC
Output Voltage-Channel 2: 15 VDC
Maximum Operating Temperature: + 71 C
Minimum Operating Temperature: - 10 C
