Differential pressure
Resolving power: 0.1 Pa
Precision guaranteed range: ±1000 Pa
Excess pressure on sensors: 5 MPa
Sensor precision: ±2.5% of rdg ±1Pa, however 50Pa or below is ±2Pa
Display units
Test Pressure:kPa, MPa
(Non-SI units for overseas: PSI, kg/cm2, bar, mbar, mmHg, cmHg, inHg, etc.)
Leak volume: mL/min, L/min, mL/s, Pa/s, Pa/min, Pa, kPa, Pa・m3/s, E-3 Pa・m3/s , etc.(Non-SI units for overseas: mmH20, mmHg, inH20, etc.)
Displayed leak volume: 4 digits, sample rate: 10/second
Number of Channels: 32ch（0～31）
Timer setting range: 999.9 seconds (resolving power: 0.1 second)
Power Source: AC100～240V±10%, 50/60Hz, 70VAmax
Test pressure source: Uses clean air.The original pressure must be sufficiently higher than the test pressure.
Pilot pressure source: Applies 400 to 700kPa of clean air.
CPU: SH-2A 144MHz, DRAM 8MB
Pipe connection diameter: Rc1/4 (test pressure supply, workpiece piping, master piping) 6mm one-touch joint (pilot air supply)
Ambient temperature: Operating temperature 5 to 45°C Storage temperature: -20 to 60°C
Humidity: 80 %RH or less No dew condensation
Mass: Approx. 10kg
USB Port
Saving data: Saves decisions, leak values, test pressure, WK#, CH#, and time on inserted memory.
Set value output: Set values of all settings screens
Standard accessories
Power cord: For use in Japan: Rating: AC125V/7A, length: 3m
For export: Rating: AC240V/10A, length: 2m (CE conformant product)
Control I/O connector, cap for RS-232C, USB cover, test report, traceability documents, user manual
