Width: 7.62 mm
Height: 2 mm
Length: 7.62 mm
Pushing: 1.5 MHz/V
Frequency: 1.7 GHz to 1.85 GHz
Power - dBm: 5 dBm
2nd Harmonic: - 15 dBc
Current Rating: 30 mA
Mounting Style: SMD/SMT
Load Capacitance: 47 pF
Phase Noise Type: - 100 dBc/Hz
Termination Style: SMD/SMT
Tuning Sensitivity: 53 MHz/V
Supply Voltage - Max: 5.25 V
Supply Voltage - Min: 4.75 V
Tuning Voltage Range - Vt: 300 mVDC to 4.7 VDC
Maximum Operating Temperature: + 70 C
Minimum Operating Temperature: - 20 C
