Measuring range: -80 ... 20 ° C pressure drop point. dew point at ° Ctd
0 ... 100% RH
-30 ... 70 ° C
Output: 4 ... 20mA
Type 0699.0401, FA 400 -20 ... 50 ° Ctd ≙ 4 ... 20 mA
Type 0699.0402, FA 400 -80 ... 20 ° Ctd ≙ 4 ... 20 mA
Type 0699.0403, FA 400 -60 ... 30 ° Ctd ≙ 4 ... 20 mA
Accuracy: Typical ± 2 ° Ctd from -80 ... -40 ° Ctd
± 1.5 ° Ctd from -40 ... 0 ° Ctd
± 1 ° Ctd from 0 ... 20 ° Ctd
Pressure range: -1 ... 50 bar standard, high pressure version up to 350 bar
Power supply: 24 VDC smooth (16 ... 30 VDC / 60 mA)
Output: 4 ... 20 mA 3-Draht-Technik
Protection class: IP 65
EMV: DIN EN 61326
Operating Temperature: 0 ... 50 ° C
Storage temperature: -40 ... 80 ° C
The load for the output is similar: <500 Ohm
Threaded screw: G 1/2 "in stainless steel
Connector: M12, 5 pole
Response time t95: <30 seconds (dry)
<10s (wet)
Display: 4 digit LCD
Relay warning: max. 60 V, 0.5 A, NO open in case of alarm and power failure, value adjustment by keypad
