CUI Inc PYBE30-Q24-S12H-DIN Isolated dc-dc isolated, 30 W, 9-36 Vdc input, 12
Manufacturer: CUI Inc Model: PYBE30-Q24-S12H-DIN - Contact
Width: 31.5 mm
Height: 25.8 mm
Length: 76 mm
Output Power: 30 W
Input Voltage: 9 V to 36 V
Mounting Style: DIN Rail
Isolation Voltage: 1.5 kVDC
Number of Outputs: 1 Output
Input Voltage - Max: 36 V
Input Voltage - Min: 9 V
Input Voltage, Nominal: 24 V
Output Current-Channel 1: 2.5 A
Output Voltage-Channel 1: 12 V
Maximum Operating Temperature: + 80 C
Minimum Operating Temperature: - 40 C
