Display Mode:
Material thickness digits display: ✓
Measurement Range: PE: 0.63 - 914.4mm (0.025 - 36"); EE: 2.54 - 152.4mm (0.100 - 6.0“)
Measurement Resolution: 0.01mm (0.001”)
Velocity Calibration Range: 305 - 18542m/s (0.0120 - 0.7300in/μs)
Additional Features:
Velocity Settings: -
High Speed Scan Mode: ✓
Differential Mode: ✓
Limit alarm mode: ✓
Memory and Data Logging: Sequential data storage, 40 files of 250 readings per file, for 10,000 readings
Transducer Probe Type: Dual element
Transducer Frequency Range: 1 - 10MHz
V-path / dual path error correction: Automatic
Probe Zero: Manual (via integrated probe disk)
Display: 12.7mm (1/2") 4.5 digit LCD
Units (selectable): mm or inches
LED Backlight: on/off/auto
Repeatability / Stability Indicator: ✓
:
Operating Temperature: -30 to 75ºC (-22 to 167ºF)
Power Supply: 2 x AA batteries
Battery Life: Alkaline – 45 hrs and Nicad – 23 hrs
Gauge Weight: 312g (11oz) - including batteries
Gauge Dimensions: 63.5 x 131 x 31.5mm (2.5 x 5.17 x 1.24”)
Packing List: Unit, Selectable Transducer, Couplant, Manual, Plastic Carrying Case, Certificate of Calibration and AA Batteries. PC Software and Data Transfer Cable included with data logging gauges. PC software available for download from our website.
