Width: 115 mm
Height: 30 mm
Length: 215 mm
Industry: Household
Approvals: IEC 60335-1, EN 60335-1, IEC 61558-1, EN 61558-1
Efficiency: 90.5 %
Unit Weight: 643 g
Output Power: 320 W
Input Voltage: 90 VAC to 264 VAC
Mounting Style: Panel
Input Frequency: 50 Hz to 60 Hz
Load Regulation: Regulated
Isolation Voltage: 4 kVAC
Number of Outputs: 1 Output
Open Frame/Enclosed: Enclosed
Output Current-Channel 1: 26.7 A
Output Voltage-Channel 1: 12 VDC
Maximum Operating Temperature: + 70 C
Minimum Operating Temperature: - 30 C
