Internal Dimension:W2000 X D3000 X H2000mm
External Dimension:W2450 X D3300 X H2900mm
Equipment weight: Approx 9 ton
Power Supply:AC 380V,8.0KW
Pressure Range:10.0KPa—101.3KPa (Adjustable)
Pressure Reducing Time:Less than 30 min
Pressure Recovery Time:Less than 30 min
Pressure Maintenance:≧10 hours
High Tension Terminal:4 pieces, Max. DC 500A,1000V
Low Tension Terminal:4 pieces, Max. DC 500A,1000V
Data Cable Interface:2 groups, DB9 line
Observe Window:W400 X H600 mm
Auto Door:Adopt hydraulic automatic open design
Inner Material:SUS304# stainless steel+45# steel
External Material:SECC steel plate，powder painted
Power Supply:AC 380V,6.0KW
Other Requirement:PLC touch screen control + computer remote control.
Can be charged and discharge in vacuum condition.
The inner chamber has signal wire interface.
Lighting system and video monitor system
Slide rail installed, the test object can be carried into and out automatically.
