Technical Specifications
Input voltage: DC 24V ±10%
Input current: Max. 300mA (Controller & Ionizer 1ea); Max. 1A (Controller & Ionizer 4ea)
Power consumption: Max. 8W (Controller & Ionizer 1ea); Max. 27W (Controller & Ionizer 4ea)
Emitter voltage: ±5.5kV
Output frequency: 1.0Hz ~ 30Hz (Adjustable)
Ion generating method: Corona discharge
Voltage application method: Pulsed AC
Material: Body: ABS / Emitter pins: Tungsten
Emitter replacement: Replaceable
Ion balance: Under average ±30V
Coverage distance: 200mm ~ 2000mm
Compressed Air Specifications
Type: CDA (Clean Dry Air), N2
Pressure: 0.05 ~ 0.5 MPa (Usually under 0.3MPa)
Flow (Per 1 emitter): 2L/min (±10%) (Under 0.1MPa)
Air tube diameter: Ø6 (Outside)
Environmental Conditions
Ozone generation: Under 0.005ppm
Ambient temperature: 0°C ~ +50°C (32°F ~ 122°F)
Ambient humidity: 35% ~ 85%RH (No condensation)
Length: 622mm
