DriveTest FM300 Closing Force Measuring Device for elevator doors (0~750 N)

- FM300:

Measuring range: 0 ... 750 N

Accuracy: +/– 3 N or 3 % of reading

Stiffness: 25 N/mm

Gap width: 145–510 mm / 5.7-20"

Diameter: 58 mm / 2.2"

Measuring principle: DMS transducer

Dimensions: 290 x 140 x 60 mm / 11.4 x 5.5 x 2.3"

Weight: 1.7 kg / 3.7 lb

- Display device SEB2:

Display device SEB2 data logger unit with LCD display and LED status indicators, control button, serial interface

Optional PC-controlled measurement

9 V battery supply

Real time clock

Memory for 100 measurements

Sensor and PC interface

Peak display

Rating display i. O./n. i. O.

- PC evaluation software PinchPilot:

Multilingual (DE, EN, IT, FR, ES)

Graphic representation of the force curve

Calculation of the standard-relevant characteristic values

Evaluation according to different guidelines possible

Custom policy adjustable

Log printout

Data export (Excel, CSV, PDF)

Optional measuring point identification

- System requirements software PinchPilot (see tab Software/App)

Delivery Scope:

1 x Closing force measuring device FM300 with 2.5 m connection cable

1 x Display device SEB2 separate measured value acquisition module with LCD display, LED display, Membrane button and serial interface

1 x 9V block battery

1 x Transport case with foam insert for the complete scope of delivery

1 x PC connection cable (USB)

1 x USB data stick with PC evaluation software PinchPilot and documentation

1 x Manual

1 x ISO Calibration Certificate
