Technology:
Sensor: Single-glass a-Si-TFT
Scintillator: DRZ-High with Cu filter
Active area: 430 x 1075 mm
Pixel matrix: 3072 x 7680
Pixel pitch: 140 μm
ADC: 16 bits
Interface:
Data interface: 10 G Ethernet
Max frame rate: 10 fps (1×1) / 20 fps (2×2)
Mechanics:
Dimensions (H x W x D): 1200 x 610 x 40 mm
Weight: 30 kg
Environmental:
Temperature: 10~35°C (operating); -10~50°C (storage)
Humidity: 30~70% RH (non-condensing)
IP rating: IP65
Power:
Dissipation: 35 W
Applications: High Energy NDT with Linear Accelerator
