Weight: 9 oz
Accuracy: ± 1.8°F + ± 0.3% of span
Compliance: CE, cULus
Input Type: Thermocouple, RTD, DC Voltage or DC Current
Output Note: Voltage pulse: 12 V (max. 40 mA) Relay: SPST, 5 A @ 250 VAC resistive
Switch Type: SPST
Display Note: Process value: 4 digit, 0.47˝ H (12 mm), orange LCD; Set point value: 4 digit, 0.47˝ H (12 mm), green LCD
Display Type: LCD
Accuracy Note: ± 1.8°F plus ± 0.3% of span (± 1°C plus ± 0.3% of span) at 77°F (25°C) after 20 minutes warm up
Memory Backup: Non-Volatile
Switch Rating: 5 A @ 250 Vac
Control Output: SPST Relay
Data Interface: RS-485 Modbus ASCII/RTU
Supply Voltage: 100 to 240 Vac
Output Type (A): Voltage Pulse
Output Type (B): Relay
RTD Input Range: JPt 100: -4 to 752°F; Pt 100: -328 to 1562°F; Ni 120: -112 to 572 °F; Cu 50: -58 to 302 °F
Number of Digits: 4
Enclosure Ratings: IP66
Power Consumption: max 5 VA
Supply Power Note: 100 to 240 VAC -20/+8%, 50/60 Hz; Optional 24 VDC, ± 10%
Supply Power Type: AC
Controller Options: Input Retransmission, Remote Setpoint
Voltage Input Range: 0 to 5 V, 0 to 10 V
Current Output Range: N/A
Input Control Signal: 0 to 20 mA
Mounting Orientation: 1/16 DIN
Voltage Output Range: 12 Vdc
Additional Features 1: Input Retransmission, Remote Setpoint
Temperature Sensor Type: RTD or Thermocouple
Storage Temperature, Max: 150 °F
Storage Temperature, Min: -42 °F
Operating Temperature, Max: 122 °F
Operating Temperature, Min: 32 °F
Thermocouple Input Range Note: Type K: -328 to 2372°F; Type J: -148 to 2192°F; Type T: -328 to 752°F; Type E: 32 to 1112°F; Type W: -328 to 2372°F; Type R: 32 to 3092°F; Type S: 32 to 3092°F; Type B: 212 to 3272°F; Type L: -328 to 1562°F; Type U: -328 to 932°F, Type TXK: -328 to 1472 °F
