Weight: 13 oz
Accuracy: ± 0.25% span ± 1°
Isolation: 1500 Vac
Input Type: Thermocouple
Output Note: Relay: SPDT, 10 A @ 240 VAC resistive.
Switch Type: SPDT NO/NC, Selectable
Display Note: Two-4 digit, 7 segment, 0.56" high LED
Display Type: LED
Memory Backup: Non-Volatile
Switch Rating: 10 A @ 240 Vac
Control Action: Selectable for Reverse (Usually Heating) or Direct (Usually Cooling)
Control Output: SSR Relay
Supply Voltage: 100 to 240 Vac/132 to 240 Vdc
Impedance Input: 3 MΩ
Output Type (A): Relay
Output Type (B): N/A
Number of Digits: 4
Enclosure Ratings: IP65, NEMA Type 4X
Power Consumption: max 5 VA
Supply Power Note: 100-240 VAC nominal, ± 10%, 50-400 Hz, single phase; 132-240 VDC nominal, ± 10%
Supply Power Type: AC/DC
Display Resolution: 1° / 0.1°
Mounting Orientation: 1/4 DIN
Temperature Sensor Type: Thermocouple
Operating Temperature, Max: 131 °F
Operating Temperature, Min: 14 °F
Thermocouple Input Range Note: Type K: -328 to 2372°F; Type J: -148 to 2192°F; Type T: -328 to 752°F; Type E: 32 to 1112°F; Type L: -328 to 1562°F
