Cv Factor: 5.4 gal/min
Materials: PVC, Polycarbonate
Cycle Time: Opening time: 50 to 65 s
Valve Type: 3-way
Wire Gauge: 18 AWG
Port 1 Size: 3/4 in
Port 1 Type: NPT Female
Port 2 Size: 3/4 in
Port 2 Type: NPT Female
Supply Voltage: 120 Vac
Pressure Limits: Up to 300 psi
Enclosure Ratings: General purpose
Materials, Wetted: Brass, Buna-N (NBR), Stainless Steel
Power Consumption: 2.5 VA
Supply Power Type: AC
Close-off Pressure: 43 psi
Flow Characteristic: Quick Opening
Media Compatibility: Alcohols, Argon, Compatible Gases, Compatible Liquids, Nitrogen, Oils, Water
Input Control Signal: Floating: 3-wire
Electrical Connection: Cable
Process Temperature, Max: 201 °F
Process Temperature, Min: 37 °F
Operating Temperature, Max: 104 °F
Operating Temperature, Min: 32 °F
