Weight: 5.5 oz
Probe Length: 10 in
RTD Accuracy: ± 1°F
Output Detail: 2 channels each 4-20 mA. Loop powered on the RH channel
Output Signal: Current
Probe Diameter: 0.3125 in
Proof Pressure: Up to 1 psi
Supply Voltage: 10 to 35 Vdc
RTD Input Range: 32 to 212°F
Measurement Type: Temperature, Humidity
Relative Humidity: 0 to 100% RH
Supply Power Type: DC
Media Compatibility: Clean Dry Air
Current Output Range: 4 to 20 mA
Mounting Orientation: Not Position Sensitive
Electrical Connection: Screw Terminal
Process Temperature, Max: 140 °F
Process Temperature, Min: 32 °F
Operating Temperature, Max: 140 °F
Operating Temperature, Min: 32 °F
Relative Humidity Accuracy: ± 2% RH
Solid State Band Gap Temperature Input Range: 32 to 212°F
