Dwyer AFS-251 Adjustable Flow Switches for Oils & Gases, 0.5-20 GPM, Piston Design (Gauge)

Filter: 50 μ or better

Weight: 1.22 kg

Accuracy: ± 10 %

Compliance: CE

Wire Gauge: 18 AWG

Port 1 Size: 1/2 in

Port 1 Type: NPT Female

Port 2 Size: 1/2 in

Port 2 Type: NPT Female

Sensor Type: Gases

Switch Type: SPDT NO/NC, Selectable

Accuracy Note: ± 10% of set point

Pressure Type: Gauge

Repeatability: ± 1%

Switch Rating: 0.17A@120Vac,0.08A@240Vac,0.13A@120Vdc,0.06A@240Vdc

Pressure Limits: Up to 5 psi

Sensor Material: 316 Stainless Steel, Fluoroelastomer, Epoxy

Repeatability Note: ± 1% max deviation

Mounting Orientation: None

Pressure Limits Note: 1000 psi (68 bar)

Electrical Connection: Pigtail Leads

electrical-connection: Pigtail Leads

Actuation Set Point, Max: 75 SCFM

Actuation Set Point, Min: 1 SCFM

Operating Temperature, Max: 300 °F

Operating Temperature, Min: -20 °F
