Weight: 1.4 lb
Accuracy: ± 0.5 % of reading, + 0.2 % FS
Body Size: Low Flow
Materials: Fluoroelastomer
Compliance: CE
Display Note: 2 x 16 character OLED (model selectable)
Display Type: LED
Relay Rating: Programmable Solid State Relay
Output Detail: 0-5 VDC default (4-20 mA, 0-10 VDC display selectable)
Output Signal: Current, Voltage
Pressure Type: Gauge
Repeatability: ± 0.2%
Response Time: 150 ms
Data Interface: RS232, RS485
Supply Voltage: 12 to 26 Vdc
Pressure Limits: Up to 120 psi
Materials, Wetted: 316 Stainless Steel, 416 Stainless Steel, Alumina Ceramic, Epoxy, FKM, Glass, Gold, Silicone, Steel
Supply Power Type: DC
Media Compatibility: Argon, Compatible Gases, Nitrogen
Particulate Size, Max: 20 microns
Leak Rate Under Vacuum: less than 10^⁻9 cc He/s
Process Connection Size: 1/8 in
Process Connection Type: Compression Fitting
Volumetric Flow Rate, Max: 200 ml/min
Volumetric Flow Rate, Min: 0 ml/min
Operating Temperature, Max: 140 °F
Operating Temperature, Min: 14 °F
