Dwyer DPMA-504 LCD Digital Panel Meter, 3.5-Digit, 4-20 mA & 0-10 Vdc, 1/8 DIN (Voltage, LCD, 12 Vdc/24 Vdc)

Weight: 4 oz

Accuracy: ± 0.05 % + 1 count

Mounting: Snap-In Panel Mount or Clamp (Gasket included)

Polarity: Automatic, positive implied, negative polarity indication

Impedance: 390 Ω

Input Type: Voltage

Display Type: LCD

Warm Up Time: 10 min

Sampling Rate: 3 Hz (3 updates/second)

Supply Voltage: 12 Vdc/24 Vdc

Backlight Power: 24 Vdc @ 35 mA

Span Adjustment: ± 1999 Counts

Number of Digits: 3.5

Decimal Selection: 3-Position, User Selectable

Supply Power Type: DC

Voltage Input Range: 0 to 200 mVdc, 0 to 5 Vdc, 0 to 10 Vdc

Display Segment Color: Green

Electrical Connection: Screw Terminal

Display Segment Height: 25 mm (1.0 in)

Storage Temperature, Max: 158 °F

Storage Temperature, Min: -4 °F

Number of Display Segments: 7

Operating Temperature, Max: 122 °F

Operating Temperature, Min: 32 °F

Front Panel Display Readings: °F, °C, %, psi

Zero Setting Adjustable Range: ± 1999 Counts
