Accuracy: ± 0.4 % + 4 digits
Impedance: Volts: 3 M Ω (106), Amps: 12 m Ω (10-3)
Input Type: Voltage, Current
Display Note: Range: -1999 to 9999 (DC) 0 to 9999 (AC), Type: 4 red digits 10 mm, Reading Rate: 4/s, Overflow Indication: OVR
Warm Up Time: 5 min
Display Range: DC: -1999 to 9999 , AC: 0 to 9999
Sampling Rate: 4 Hz (4 updates/second)
Supply Voltage: 24/48 Vac
Number of Digits: 4
Enclosure Ratings: IP66, NEMA Type 4X
Relative Humidity: <95% @ 40°C, Non-Condensed
Supply Power Type: AC
Current Resolution: 1 mA
Voltage Resolution: 0.1 V
Current Input Range: 1 A ac, -1.999 to 5 A dc
Voltage Input Range: ± 100 Vac, 600 Vac, -200 to +600 Vdc
Display Segment Color: Red
Display Segment Height: 10 mm (0.4 in)
Temperature Coefficient: 100 ppm/°C
Storage Temperature, Max: 185 °F
Storage Temperature, Min: -13 °F
Operating Temperature, Max: 140 °F
Operating Temperature, Min: 14 °F
