Dwyer TUF-1250-BN Compact Ultrasonic Energy Meter for Heating/Cooling with Flowmeter & Calculator (8.8 GPM, 5 in)
Manufacturer: Dwyer Model: TUF-1250-BN - Contact
Weight: 21.1 lb
Accuracy: ± 2 %, ± 5% with transitional flow
Body Size: DN125
Materials: Plastic
Compliance: CE
Display Type: LCD
Repeatability: 0.01
Data Interface: BACnet
Flow Direction: Unidirectional
Pipe Size, Max: 5 in
Supply Voltage: 24 Vac/Vdc
Pressure Limits: Up to 362 psi
Number of Digits: 8
Enclosure Ratings: IP65
Materials, Wetted: 316L Stainless Steel, Brass
Power Consumption: 1 W
Relative Humidity: <93%
Supply Power Note: 24 Vdc/Vac (model dependent)•• or 3.6 V ER26500 lithium metal battery, user supplied and installed, battery acts as back-up if power is lost
Supply Power Type: AC/DC
Pressure Drop, Max: 1.5 psi
Media Compatibility: Alcohols, Compatible Liquids, Oils, Water
Mounting Orientation: Horizontal, Vertical
Electrical Connection: Screw Terminal
Nominal Flow Rate, Max: 440 gal/min
Process Connection Type: Flange
Process Temperature, Max: 203 °F
Process Temperature, Min: 36 °F
Volumetric Flow Rate, Max: 881 GPM
Volumetric Flow Rate, Min: 8.8 GPM
Operating Temperature, Max: 131 °F
Operating Temperature, Min: 41 °F
