Digits:Main parameter: 5 digits; secondary parameter: 5 digits
Measurement Parameter: Main parameter: L/C/R/Z; secondary parameter: X/D/Q/θ/ESR
Measurement Range(L): 0.01μH - 9999H
Measurement Range(C): 0.01pF - 99999μF
Measurement Range(R): 0.0001Ω - 99.99MΩ
Basic Accuracy: 0.2%
Test Frequency (Hz): 100~20kHz 12point
Measurement Display Speed: 2 times/second (slow), 4 times/second (medium speed), 8 times/sec (fast)
Internal Bias: 0-1500mV adjustable, 1mV stepping
Test Level: 100mV、300mV、600mV、1000mV、1500mV、2000mV
Correction Function: Open circuit correction, short circuit correction
Screening function: The screening limit can be set from -50% to + 50% with fixed points of 1%, 5%, 10% and 20%
Communication Interface: Standard configuration: USB, RS232 (or 485), Handle interface; Optional: GPIB, USB Host
Others: Support DCR, electrolytic capacitor measurement mode, adjustable backlight brightness, optional in English and Chinese
General Technical Specifications
Power supply voltage: 220V AC ± 10%, or 110V AC ± 10%, 45-65Hz
Working environment: 0 ~ 40 ℃, relative humidity <80%.
Storage environment: -10 ~ 50 ℃, relative humidity <80%.
Dimensions: 265mm * 105mm * 305mm (width * height* depth).
Mass: 2.3kg.
Standard Accessories:
Four-terminal-pair Kelvin test cable (35A51).
Three-core power cord (30A51).
One User Manual.
Optional accessories:
RS232 serial cable/USB data cable.
Handle cable.
Four-terminal-pair Kelvin test fixture (including short block)
SMD component test fixture (including short block)
