EAST TESTER ET5410 Programmable DC Electronic Load (0 ~150V)

Channel NO.: 1

Rated input

Power: 400W

Input voltage: 0-150V

Input current: 0-40A

CV: 0.1~19.999V/0.1~150.00V

CC: 0~3.000A; 0~40.00A

CR: 0.05Ω~10Ω; 10Ω~7.5kΩ

CP: 0~400W

Battery test function

Voltage range: 0~120V

Discharge capacity: 240Ah

Resolution: 1mA

Test time: 1s~16h

Measuring range:

Voltage readback: 0~19.999V; 0 ~150.00V

Current readback: 0~3.000A; 0~40.00A

Power readback: 400W

Scope of protection: OVP, OCP, OPP, Short circuit

General technical specifications:

Power voltage: 220Vac±10%, optional 110Vac±10%, 45-65hz

Display: 2.8-inch TFT LCD, resolution 320 x 240

Operating temperature: 0 ℃ to 40 ℃

Storage temperature: - 10 ℃ to 70 ℃

Relative humidity: < 80%

Interface: standard USB Device, RS232(or 485)

Size: 90mm * 190mm * 300mm (width * height * depth)

Standard accessories:

One three-core power cord

Two power fuses

1 user manual

Optional accessories:

 CD

USB cable

RS232/485 cable

The output line
