Test Force:
gf: 10gf, 25gf, 50gf, 100gf, 200gf, 300gf, 500gf, 1000gf
N: 0.098N, 0.246N, 0.49N, 0.98N, 1.96N, 2.94N, 4.90N, 9.80N
Test Range: 5HV - 3000HV
Test Mode: HV/HK
Loading Method: Automatic (Loading/Dwell/Unloading)
Turret: Automatic Shifting
Conversion Scale: HK, HRA, HRB, HRC, HRD, HRE, HRF, HRG, HRK, HR15N, HR30N, HR45N, HR15T, HR30T, HR45T, HS, HB
Data Output: Built-in Printer; WORD or EXCEL Report with Curve Chart
Hardness Reading: Indentation Displaying and Automatic Measuring on PC
Objective: 10X(Observe), 40X (Measure)
Eyepiece: 10X
Total Magnification: 100X, 400X
Resolution: 0.0625μm
Dwell Time: 1 - 99s, each step 1 second
Light Source: LED Cold light source
Motorized X-Y Table Size: 110 × 110mm; Travel: 50 × 50mm; Resolution: 0.002mm
Test space: Height: 100mm; Depth: 98mm
Execute Standard: ISO 6507, ASTM E384, JIS Z2244, GB/T 4340.2
