Product available in APAC region only
OUTPUT
• Phase: 1Ø
• Power Rating: 10kVA
• Voltage:
Range: 0-150V/0 - 300V or 0-175V/0 - 350 Selectable (Optional 0 -350V) or 0 - 300V/0-600V Selectable (Optional 0-600V)
Resolution: 0.1V
Accuracy: ±(1% of setting + 2 counts)
• Max. Current rms: 0 - 150V: 84.0A; 0 - 300V: 42.0A
• Frequency:
Range: 45.0 – 70.0Hz/45.0-500.0Hz (Optional 45-500Hz) Full Range Adjust
Resolution: 0.1Hz / 1Hz
Accuracy: ±0.02% of setting
• Total Harmonic Distortion (THD): < 1% for 110/220V, 50/60Hz for 300V and Option 350V at Resistive Load
• Inrush Current: 3 times rated Current(r.m.s)
• Crest Factor: 3 times rated Current(r.m.s)
• Line Regulation: ± 0.1V
• Load Regulation: ±(0.5% of output + 0.5V) at Resistive Load
INPUT
Phase: 3Ø4W
Voltage: 220 (L-N)/380 VAC (L-L) ±10%
Max. Current: 25A
Frequency: 47-63 Hz
Power Factor: 0.8
GENERAL
• Display: 4 group of digital LED displays
• Interface: Standard USB & RS232, Optional GPIB & Analog card
• Dimensions (WxHxD, mm): 430 x 472 (839) x 650 (730)
• Weight: 128kg
