EEC 7316 AC Ground Bond Tester (60A/12V; 0-600mΩ)

• Voltage (AC): 115/230V ± 15% Auto Range

• Frequency: 50/60 Hz ± 5%

• Output Rating (AC): 60A/12V max

• Output Voltage: 12V

• Current Measurement Range: 1.00-60.00A

• Current Resolution: 0.01A

• Current Accuracy: ±(3% of reading + 3 counts)

• Resistance Measurement Range: 0-600mΩ

• Resistance Resolution: 1mΩ

• Resistance Accuracy:

0-600mΩ under 1.00-5.99A: ±(3% of reading +3 counts)

0-600mΩ under 6.00-15.00A: ±(2% of reading + 2 counts)

0-300mΩ under 15.01-30.00A: ±(2% of reading + 2 counts)

0-150mΩ under 30.01-60.00A: ±(2% of reading + 2 counts)

• Memory: 10 memories, 3 steps/memory

• Display: 128 x 64 Graphic LCD

• Dimension (W × H × D), mm: 215 x 89 x 430

• Weight: 14kg
