AC OUTPUT
• Phase: 1Ø
• Power Rating: 1kVA
• Voltage:
Range: 5 - 300V, 150/300V Auto
Resolution: 0.1V
Accuracy: ±(1% of setting + 2 counts)
• Max. Current rms (0 - 150Vac): 9.2A
• Max. Current (0 - 300Vac): 4.6A
• Frequency:
Range: 40 – 1kHz Full Range Adjust
Resolution: 0.1Hz at 40.0 - 99.9 Hz, 1Hz at 100 - 1kHz
Accuracy: ±0.03% of setting
• Total Harmonic Distortion (THD): < 0.3% at 110/220V & 50/60Hz (Resistive Load)
• Inrush Current: 4 times rated Current(r.m.s)
• Crest Factor: 3 times rated Current(r.m.s)
• Line Regulation: ± 0.1V
• Load Regulation: ±(1% of output + 1V) at Resistive Load
DC OUTPUT
• Power rating: 1kW
• Voltage
Range: 0 - 210V/0 - 420V Selectable
Resolution: 0.1V
Accuracy: ±(1% of reading + 2 counts)
• Max. Current (r.m.s)
0 - 200V: 4.8A
0 - 400V: 2.4A
• Ripple and Noise (r.m.s): Range: L < 500mV; H < 800mV
• Ripple and Noise (p-p): < 3Vp-p
• Line Regulation: ± 0.1V
• Load Regulation: ±(1% of output + 1V) at Resistive Load
INPUT
• Phase: 1Ø
• Voltage: 100-240Vac±10%
• Max Current: 15A
• Frequency: 47 - 63Hz
• Power Factor: 0.97
GENERAL
• Interface: Standard USB & RS232, Optional GPIB, Ethernet, Linking Card
• Dimensions (WxHxD, mm): 430 x 133 (146.5) x 530 (590)
• Weight: 20kg
