• Voltage (AC): 100-120V ± 10%, 200-240V ±10%
• Apparent Power: 850VA
• Frequency: 50/60 Hz ± 5%
• Output Rating (AC): 40A/8V max
• Output Voltage: 8V
• Current Measurement Range: 1.00-40.00A
• Current Resolution: 0.01A
• Current Accuracy: ±(3% of reading + 3 counts)
• Resistance Measurement Range: 0-600mΩ
• Resistance Resolution: 1mΩ
• Resistance Accuracy:
0-600mΩ under 1.00-5.99A: ±(3% of reading + 3 counts)
0-600mΩ under 6.00-10.00A: ±(2% of reading + 2 counts)
0-200mΩ under 10.01-30.00A: ±(2% of reading + 2 counts)
0-150mΩ under 30.01-40.00A: ±(2% of reading + 2 counts)
• Memory: 10 memories, 3 steps/memory
• Display: 128 x 64 Graphic LCD
• Interface: RS-232
• Dimension (W × H × D), mm: 215 x 89 x 430
• Weight: 5.5kg
