Size of Spectrometer: 560mm*380mm*410mm
Size of sample chamber：460mm*310mm*95mm
Size of Vacuum sample chamber：Φ150mm×75mm
Weight: 45Kg
Element Range：Na11-U92
Analysis content range：1ppm- 99.99%
Detector：AmpTek high resolution SDD
DPP Analyzer: 4096 Channel DPP analyzer
Excitation Source：50W X-ray tube
HV unit：0-50kV
Power supply：220ACV 50/60HZ
Environment：-10 °C - 35 °C
Accessory
>Standard
Ag- Calibration standard
Vacuum pump
Sample cup
USB cable
Power supply cable
Test Mylar
Calibration report
Warranty card
>Optional
Mill machine
Sample pressing machine
Drying oven
Fusing bead machine
Balance
Mineral Standard samples
Power stabilizer
EDXRF Applications
EDXRF spectrometers are the elemental analysis tool of choice, for many applications, in that they are smaller, simpler in design and cost less to operate than other technologies like inductively coupled plasma optical emission spectroscopy (ICP-OES) and atomic absorption (AA) or atomic fluorescence (AF) spectroscopy. Examples of some common EDXRF applications are: Cement and raw meal: sulfur, iron, calcium, silicon, aluminum, magnesium, etc; Kaolin clay: titanium, iron, aluminum, silicon, etc; Granular catalysts: palladium, platinum, rhodium, ruthenium, etc; Ores: copper, tin, gold, silver, etc; Cement and mortar fillers: sulfur in ash; Gasoline, diesel and RFG: sulfur, manganese, lead, etc; Residual gas oils: sulfur, chlorine, vanadium, nickel, etc; Secondary oil: chlorine, etc; Kerosine, naphtha: sulfur, etc; Crude oil and bunker fuels: sulfur, vanadium, nickel, etc; Plating, pickling & pre-treatment baths: gold, copper, rhodium, platinum, nickel, sulfates, phosphates, chlorides, etc; Acetic acid: magnesium, cobalt and bromine; Terephthalic acid (TPA): cobalt, manganese, iron, etc; Dimethyl terephthalate (DMT): heavy metals; PVC copolymer solutions: chlorine; Photographic emulsion: silver; Clay: metals and non-metals; Waste and effluent streams: RCRA metals, chlorides, phosphates, etc; Food, pet food and other animal feed: potassium, phosphorus and chlorine; Cosmetics: zinc, titanium, calcium, manganese, iron, silicon, phosphorus, sulfur, aluminum, and sodium; Wood treatment: CCA, Penta, ACQ, ACZA, phosphorus-based fire retardants, copper naphthanate, zinc napthanate, TBTO, IPBC and combinations of these; Antacids: calcium; and Toothpaste: phosphorus and tin.
